Architecture and Urbanism Indoor wind environment in buildings for Qinghai-Tibet plateau of China

those in the West District Sutra Hall. The internal atrium,
located on the south side, measures 7.8 m × 5.2 m. The
vent, measuring 1.2 m × 2.0 m, is located in the middle
of the eastern ceiling. The sunroom is cantilevered outside
the main wall and connected to the East District Sutra Hall
through an archway, with all of its walls made from thin
wooden panels.
The printing space is located on the northwest side of
the building, with an overall height of 4.9 m. This space
allows direct air exchange with the outdoors through the
internal atrium that opens to the roof. Apart from the
column structure, wooden shelves are placed along the
walls, with the printing work area situated in the center.
Figure 3. Aerial view of the Dege Scripture Printing House. Source: Across field mapping and 3D scanning, the architectural
Drawing by Zhong (created with SketchUp) features of the DSPH can be summarized. These features
include higher floor heights, internal and external atriums,
numerous windows and vents, a sunroom, a variety
of structural materials, a thick roof, and a distinctive
architectural layout.
3. The DSPH indoor wind environment test
analysis
3.1. Method
This research mainly adopts the methods of 3D laser
scanning, field testing, and CFD numerical simulation. 3D
laser scanning is used to capture the building environment
and create a digital model of the DSPH, which provides the
necessary data for wind environment software simulation.
During field visits and physical environment testing at the
DSPH, the meteorological characteristics and architectural
wind environment performance of the region are observed
and analyzed. The collected data serves as input for the
Figure 4. Map of important spatial locations. Source: Drawing by Zhong CFD simulation, which is used to simulate the wind
(created with SketchUp) environment. The CFD simulation is conducted using
the Phoenics simulation tool, which is based on the finite
windows, an internal atrium, and a vent. A total of nine volume method (He, 2020). By simulating the wind field
windows, each measuring 1.2 m in width, 1.5 m in height, of the DSPH, the study summarizes the existing passive
and 1.2 m in depth, are located on the north side of the design strategies. Across a combination of the simulation
space and are closed at night. The internal atrium, located results and the measured data, the wind environment of
on the south side of the space, measures 13.0 m × 5.2 m the DSPH is evaluated and summarized.
and connects the space to the scripture printing site and
the roof. The vent, measuring 1.2 m × 2.0 m, is located on 3.2. Wind environment test of DSPH
the east side of the ceiling’s center and is interconnected According to the 48-h temperature and wind speed data
with the scripture printing site. The main function of this measured in July 2022 at DSPH (Table 2), the average
space is to store wooden carving boards of scriptures, with outdoor temperature was 17.0°C, with a temperature
multiple wooden shelves dividing the space into multiple range from 11.6°C to 23.9°C, resulting in a temperature
vertical walkways. difference of 12.3°C. The average indoor temperature was

The East District Sutra Hall is located on the 2 floor of 15.5°C, with a temperature range of 13.6 – 19.2°C, giving
nd
the building’s northeast side and is equipped with windows, a temperature difference of 5.6°C. Notably, temperature
an internal atrium, a vent, and a sunroom. There are eight differences exist between indoor floors, with lower floors
windows on the north side with the same dimensions as generally exhibiting cooler temperatures, and higher floors
