International Journal of Bioprinting                                    3D bioprinting of collagen hydrogels




               To further verify the stability and uniformity of CML-  a 405 nm light source upon the start of extrusion printing.
            Ink, Orange G (Aladdin Biochemical Technology Co., Ltd.,   After printing the first layer, observations were made
            China) was added and mixed with CML-Ink to extract the   through photographs. Subsequently, a two-layer structure
            shape of a “butterfly” and “sun,” accompanied by 405 nm   was printed to examine the impact of accumulated printed
            blue light irradiation.                            layers on the printing size.
               To evaluate the extrudability of Col and CML-Ink,   Pentagonal and heart-shaped models were 3D printed
            they were loaded into a 5 mL syringe with a needle inner   using  CML-Ink,  followed  by  photographic  observation.
            diameter of 0.25 mm. A needle tester (BosinTech, China)   Finally, a 3D model of a rabbit’s head and ears, featuring
            was employed to measure the time-dependent extrusion   a complex structure, was designed and introduced for
            force required for Col and CML-Ink over 30 s. The materials,   3D printing.
            Col and CML-Ink, were loaded into sterile syringes, which
            were then connected to the needle device. The extrusion   2.5. Characterization of 3D-printed
            was performed at a constant speed of 10 mm/min, and the   collagen-based scaffold
            thrust magnitude was measured continuously over 30 s at   2.5.1. Scanning electron microscopyv
            room temperature.                                  The CML-Ink was extrusion-based 3D printed into porous

            2.3.4. Rheological test                            scaffolds,  named  CML-scaffold, with a  pore size  of  1.00
            Rheological tests were performed utilizing a modular   mm under the aforementioned 3D printing conditions.
            compact rheometer (MCR 302; Anton Paar, Germany)   The CML-scaffold was then subjected to freeze-drying.
            equipped with a 25 mm stainless steel parallel plate   Scanning  electron  microscopy  (SEM)  was  employed
            geometry. A multi-step rheological test was carried out   to analyze the microscopic dimensions of the lyophilized
            to assess the dynamic mechanical properties of both Col   CML-scaffold. The scaffold underwent gold spraying
            and CML-Ink before and after illumination.  The changes   treatment for 5 mins inside an ion sputtering machine
                                               48
            in the storage modulus (Gʹ) and loss modulus (G˝) of   (Hitachi, Japan). A field emission scanning electron
            Col and CML-Inks were evaluated before, after 30 s, and   microscope (Hitachi S-4800; Hitachi, Japan) was used to
            following 405 nm illumination. These measurements were   observe the size and microstructural features of the scaffold
            performed at 25 °C under an angular frequency of 1 rad/s   at a voltage of 5.0 kV.
            and a strain of 1%.
                                                               2.5.2. Mechanical characteristics
               To explore the shear-thinning properties of Col and   Rotational rheological measurements were performed
            CML-Ink, viscosity as a function of shear rate (at ω = 1 rad/s   on Col and CML-scaffold with an angular frequency of 1
            and γ = 1%) was measured over a range of 0.01–100 s-¹.    rad/s, covering a strain range of 1–100%. Additionally, a
            The dynamic step strain amplitude test, conducted at both   constant shear strain of 1% was maintained, and frequency
            low strain (γ = 1.0%) and high strain (γ = 300%) conditions   scanning was carried out on the Col and CML-scaffold in
            for three cycles, aimed to investigate the sol–gel transition   the range of 0.1–100 Hz.
            properties of Col and CML-Ink.
                                                                  Compression tests were employed to assess the
            2.4. Extrusion 3D bioprinting of CML-Ink           alterations in mechanical strength of both Col and CML-
            3D models were designed and generated in SolidWorks   scaffold at 25 °C using a universal testing machine (AGX-V
            CAD software, and subsequently saved in STL file format.    500  N;  Shimadzu,  Japan).  Cylindrical  CML-scaffold
                                                         49
            3D bioprinting was conducted using a 3D bioprinter   structures, with a height of 2 mm and a diameter of 15
            (BIOMAKER2i; Shangpu Boyuan Biotechnology Co.,     mm, were fabricated using 3D printing. Similarly, Col was
            LTD., China) equipped with a modular electric sprinkler   placed in a mold of the same size to create the cylinder.
            head compatible with a disposable standard 5 mL BD   The cylindrical hydrogels were positioned on the lower
            syringe. The CML-Ink was loaded into a 5 mL syringe for   pressure plate, and the upper pressure plate was set to
            3D printing, utilizing a 25 G needle with an inner diameter   move at 10 mm/min until rupture. Force and displacement
            of 0.25 mm.                                        were recorded in each case.
               A computer-aided design (CAD) model featuring a    The mechanical properties of the CML-scaffold were
            grid pattern (8.00 × 8.00 × 2.00 mm) was selected, with   further verified through tensile measurements. A universal
            a line distance set at 500 μm. The model was sectioned,   mechanical tester (AGX-V 500 N; Shimadzu, Japan) was
            and the printing parameters were configured as follows: a   employed to assess the tensile properties of the CML-
            printing speed of 3 mm/s, extrusion speed of 0.3 mm³/s,   scaffold. Rectangular CML-scaffold samples (25 × 5 ×1.5
            and immediate irradiation of the extruded contours with   mm) were fabricated via 3D printing. The tensile test was

            Volume 10 Issue 5 (2024)                       545                                doi: 10.36922/ijb.4069
