M. A. Aman et al. / IJOCTA, Vol.15, No.4, pp.549-577 (2025)
            significant advantages due to its inherent flexibil-  converter demonstrates superior overall suitabil-
            ity in selecting control strategies. However, using  ity for SRMs in EV applications.
            a greater number of switching devices increases
            the cost.
                                                              5. Conclusion
            4.3.2. Novel integrated power converter
                                                              This paper provides a comprehensive review of
            The NIPC topology integrates functionalities      the state-of-the-art control strategies and power
            to reduce the number of active components         converter topologies for SRMs in EV applica-
            while maintaining adequate performance, thereby   tions. Through a detailed examination of torque
            achieving a favorable balance between efficiency  control techniques, including indirect torque con-
            and cost.   Despite its integration advantages,   trol, DTC, and AI-based control strategies, this
            NIPC may face limitations in scalability and ther-  study highlights their effectiveness in mitigating
            mal management in larger SRM systems. NIPC        the drawbacks of SRMs, particularly torque rip-
            lowers the costs by requiring fewer devices and en-  ple and acoustic noise. Each strategy presents
            hancing the reliability of switch reluctance drive  distinct advantages and disadvantages, and the
            (SRD) systems. Studies indicate that all power    choice of technique depends on the desired ap-
            devices are susceptible to faults, and the impact  plication requirements. However, for EV appli-
            of these faults on the operation of NIPC differs.  cations, the DITC strategy demonstrates supe-
            A short circuit in the capacitor and diodes would  rior efficiency in mitigating torque ripple, offering
            lead to a short circuit of the power source, result-  both ease of implementation and flexibility across
            ing in complete power converter failure. Addi-    a broad range of torque and speed conditions.
            tionally, an open-circuit fault in the diodes would   In addition to control techniques, this study
            interrupt the release path of stored energy, caus-  also explored several power converter topologies
            ing overvoltage that can damage the power de-     commonly employed in SRM drives, summarizing
            vices; hence, the system cannot continue oper-    their major advantages and drawbacks. Among
            ating under the faulty diode. In contrast, when   the various topologies, surveys revealed that the
            a battery is chosen as the power source, the re-  fault tolerance, rapid demagnetization, and regen-
            sponse speed of the DC link is lowered under the  erative braking capabilities of the AHB, NIPC,
            open-circuit fault of the capacitor; however, the  and T-type converters make them particularly
            NIPC can still operate. 87  The NIPC topology is  suitable for EV applications. The AHB and NIPC
            illustrated in Figure 25C.                        converters offer a favorable cost profile while pro-
                                                              viding high efficiency and a significant capacity
            4.3.3. T-type converter
                                                              for torque ripple reduction. However, their abil-
            The T-type converter delivers a compelling com-   ity to enhance power productivity remains com-
            promise with reduced conduction losses and im-    paratively limited. In contrast, the T-type con-
            proved efficiency in medium-voltage ranges, posi-  verter represents a superior conversion mecha-
            tioning it as a strong candidate for EV applica-  nism, providing redundant switching states that
            tions. However, its control complexity and sensi-  enable both magnetization and regenerative de-
            tivity to parameter variations necessitate the use  magnetization. When paired with a four-phase
            of advanced control strategies for optimal opera-  SRM, this topology emerges as the most opti-
            tion. The T-type converter demonstrates a signif-  mal configuration due to its ability to handle high
            icant ability to mitigate torque ripple by enabling  switching frequencies and reduce switching losses,
            simultaneous magnetization and regenerative de-   while maintaining excellent fault tolerance and re-
            magnetization between two phases. Nonetheless,    liability.
            its potential for enhancing power productivity re-    By synthesizing the available research, this
            mains limited due to the limitations imposed by   study identifies a four-phase SRM coupled with
            magnetization voltage and regenerative demagne-   a T-type converter and controlled via DITC as
            tization. Besides, it also offers fault-tolerance ca-  the most promising configuration for EV applica-
            pability. The T-type converter topology is illus-  tions, as shown in Figure 27.
            trated in Figure 25D.                                 A four-phase SRM is considered, with phases
                When comparing the AHB, NIPC, and T-type      designated as a, b, c, and d, all of which are ener-
            converter topologies, the most suitable choice    gized in succession. Shared switches allow the en-
            depends on specific design priorities, such as    ergization of non-consecutive phases, specifically,
            cost, efficiency, fault tolerance, thermal man-   phases a and c, while additional shared switches
            agement, implementation complexity, and space     energize the remaining non-consecutive phases,
            constraints. As shown in Figure 26, the T-type    namely phases b and d, achieving a high level
