Page 64 - JCAU-5-3

Journal of Chinese
Architecture and Urbanism Ecosystem service evaluation on ecological restoration

Table 1. (Continued)
Land use type Revetment type Characteristics of riparian zone Typical scenarios
Hard revetment Width of 2 – 5 m; a waterfront platform or
stepped entrance to the water forms a dock;
some have planting pools with shrubs or trees

(Shantang Village)
R6 – Ecological land Soft revetment The slope length is about 3 – 5 m, and some
boundary riparian zone exceed 5 m. The slope surface is natural with a
slope of 30° – 45°, dominated by a combination
of trees and ground cover plants

(Beiguan Village)
R7 – Green space Soft revetment Slope length ranges from 3 ‒ 5 m, with a natural
boundary riparian zone slope surface and a gradient between 30° and
45°. The vegetation consists mainly of trees and
understory plants

(Shantang Village)
Source: Tabulation by the authors

Table 2. Hierarchical table of ecological service evaluation indicators for water network‑type rural riverbanks
Service type level Service dimension Primary indicator Secondary indicator Value
Crop production Crop/Agricultural Nursery economic output Fruit and vegetable output 5
product output (AP) (A )
i By-product output 3
No output 1
Supporting service Biodiversity Tree species (T ) >5 species 5
S
enhancement (BD)
3 – 5 species 3
1 – 3 species 1
Shrub species (S ) >5 species 5
S
3 – 5 species 3
1 – 3 species 1
Herb species (G ) >5 species 5
S
3 – 5 species 3
1 – 3 species 1

(Contd...)

Volume 5 Issue 3 (2023) 6 https://doi.org/10.36922/jcau.1055
