International Journal of AI for
            Materials and Design
                                                                                     ML-based MPC for multizone BAC


            predictive capabilities and overall performance of building   •   Section  3  (MPC  controller  for  ACMV):  Details  the
            automation systems.                                   design and implementation of the MPC controller for
              Despite the promise of MPC, challenges remain in    the ACMV system
            accurately modeling the complex thermal dynamics   •   Section  4 (ML  model  development for  MPC):
            of  buildings,  which  are  influenced  by  varying  weather   Outlines the development of the ML models used
            conditions, occupancy patterns, and building envelope   for forecasting and their integration within the MPC
            characteristics. In addition, the computational burden   framework
            associated with optimization across multiple zones   •   Section 5 (Results and discussion): Presents the
            presents further difficulties.  To address these challenges,   performance evaluation, key findings, and a comparative
                                  23
            model-free approaches based on RL (such as Q-learning    analysis with conventional control strategies and
                                                         24
            and deep reinforcement learning ) have been explored,   discusses the challenges encountered
                                       25
            with several studies demonstrating notable energy savings.   •   Section  6  (Conclusion):  Summarizes  the  study’s
            For instance, Ding  et al.  reported approximately 14%   contributions, implications, and suggestions for future
                                 26
            energy savings using deep RL with inputs from EnergyPlus   research.
            simulations. However, the present study focuses on MPC   2. Testbed setup
            due to its structured approach and its ability to directly
            integrate system constraints into the optimization process.  For the testbed, a commercial building located in Jurong
                                                               East, Singapore, was selected. The building is served by a
              In this paper, we present a multizone MPC framework   central chiller plant consisting of two chillers, each with
            for the coordinated control of ACMV systems, aiming to   a capacity of 438 refrigeration tons. The ACMV system in
            optimize both occupant comfort and energy efficiency. To   the building operates from 7 AM to 7 PM on weekdays.
            evaluate performance, we compare the energy consumption   The experiments were conducted in an 850 m  multiuse
                                                                                                     2
            and thermal comfort achieved using our coordinated   test space, partitioned into 11 zones, including two office
            MPC approach with those obtained from a conventional   spaces (OS1 – 2), six learning zones (LZ1 – 6), and three
            reactive control strategy employing proportional-integral-  common areas (CA1 – 3), as depicted in Figure 1. MPC
            derivative (PID) control. The key novelties of our MPC   was implemented to coordinate and control the ACMV
            system are as follows:                             systems, as illustrated in Figure 2. The test space includes
            (i)  Large-scale, multizone implementation: This study   operable partition walls between LZ1 and LZ2, as well as
               demonstrates a real-world deployment of MPC in an   among LZ4, LZ5, and LZ6. These partitioning walls can be
               11-zone building (850 m ) with actual occupancy. This   adjusted so that two zones (LZ1 and LZ2) or up to three
                                   2
               contrasts with previous studies, which were limited   zones (LZ4, LZ5, and LZ6) can be merged into a single
               to smaller-scale implementations (e.g., two zones ),   zone. The open/closed state of these walls is determined by
                                                        27
               simulated environments,  or unoccupied buildings 29  proximity sensors, which output “1” if the walls are closed
                                   28
            (ii)  Integration of ML-based weather forecasting: By   (i.e., zones remain separate, as in LZ1 and LZ2) or “0” if the
               incorporating ML-based weather  forecasting into   walls are open (zones merge into one larger room).
               the MPC framework, our system proactively adjusts
               control actions in anticipation of weather changes.   The schematic diagram of the ACMV system installed
               This represents an advancement over previous studies,   in the test space is shown in Figure 2. The ACMV system
               which typically relied on existing or historical weather   serving the test space consists of two primary air-handling
               data. 30-32                                     units (PAUs) for pre-conditioned fresh air supply and
                                                               16 fan coil units (FCUs) for cooling and dehumidification.
              This  work provides  valuable  insights  into  both   The cooling coils in the PAUs and FCUs are supplied with
            the challenges and benefits of implementing MPC in   chilled water from the building’s central chiller plant
            complex, real-world settings, particularly within tropical   (not shown in  Figure  2). Since the MPC system of this
            environments. Consequently, it contributes significantly to   study controls only the airside equipment of the ACMV
            the advancement of scalable solutions for building energy   system within the test space – a fraction of the entire
            management.                                        building – the net effect of MPC on the overall chiller plant
            This paper is organized as follows:                is  not considered. Instead, cooling energy consumption,
            •   Section 1 (Introduction):  Provides background,   measured by British thermal unit (BTU) meters (or energy
               motivation, and objectives of the study         meters) installed at the cooling coils of the PAUs and FCUs,
            •   Section 2 (Testbed setup): Describes the heating,   is used to evaluate the cooling energy consumed by the
               ventilation, and air conditioning (HVAC) system and   ACMV system in the test space. Each PAU is equipped with
               sensor configuration of the testbed             an on/off damper, a cooling coil, and a supply fan. The PAUs


            Volume 2 Issue 1 (2025)                         41                             doi: 10.36922/ijamd.8161
