CFD Assessment of Extrusion Bioprinting Parameters
Appendix
A B C
D E
Figure 1. Contour of volume fraction for extruded bioink in conical nozzle with printing speed 1 mms at (A) 2 s, (B) 4 s, (C) 6 s, (D) 8 s,
−1
and (E) 10 s.
A B C
D E
Figure 2. Contour of volume fraction for extruded bioink in conical nozzle with printing speed 5 mms at (A) 2 s, (B) 4 s, (C) 6 s, (D) 8 s,
−1
and (E) 10 s.
A B C
D E
Figure 3. Contour of volume fraction for extruded bioink in conical nozzle with printing speed 10 mms at (A) 2 s, (B) 4 s, (C) 6 s,
−1
(D) 8 s, and (E) 10 s.
