Materials Science in Additive Manufacturing                                   Functional materials for AM



            through the integration of DIW printing and automated   printed matrix and DIW-printed functional materials was
            pick-and-place of electronic components within a unified   achieved. The developed strain gauge exhibited a gauge
            manufacturing platform. Ink using silver flakes as filler in   factor of 251, indicating relatively excellent sensitivity.
            a thermoplastic polyurethane (TPU) matrix is printed as a   Advanced 3D printing techniques, such as multi-
            strain gauge, along with a pick-and-place microcontroller   material extrusion, hybrid printing, and coaxial printing,
            and LED, resulting in the development of a large-area   have emerged as powerful tools for fabricating soft sensors.
            wearable strain gauge. The developed strain gauge outputs   These 3D printing methods have particularly facilitated soft
            LED readings according to joint bending. Similarly, a   sensors  embedded  with  metallic  nanoparticles,  enabling
            moisture sensor was developed through a pick-and-place   immediate fabrication on request. The integration of metal
            hybrid procedure of DIW 3D printing and surface-mount   particles into non-conductive polymer matrices imparts
            electronic components (LEDs).  Polyethylene oxide   electrical conductivity, while the inherent flexibility of
                                       73
            (PEO) composite with silver flakes as conductive filler   polymers facilitates their applications in various fields,
            was extruded and printed in the form of an induction   such as strain sensors and wearable sensors. Despite their
            coil. When immersed in water, the printed conductive   advantages, metal particle-embedded soft materials face
            traces undergo a reverse drying process and exhibit higher   several challenges:
            impedance. Under controlled moisture, the ink maintains   (i)  High-temperature sintering: Metal nanoparticles often
            its printed shape and recovers to its initial impedance level   require high-temperature sintering (typically above
            after drying.                                         100°C) to enhance electrical conductivity, hindering
              In addition, a flexible sensor was developed to detect the   in situ fabrication within the human body.
            deformation and posture of a snake-like soft robot based   (ii)  Cost limitations: Silver nanoparticles, the most
            on liquid metal (Figure 4B).  Liquid metal-based sensors   commonly used, are expensive, thereby limiting their
                                  74
            have the advantage of measuring large deformations    suitability for mass production. Although copper
            by remaining connected even after experiencing large   nanoparticles are cheaper than silver nanoparticles,
            deformations due to their stable electrical properties.   they are less commonly used due to the aforementioned
            Since liquid metal has low printability, silicon and liquid   manufacturing difficulties.
            metal are printed together coaxially. The sensor is printed   (iii) Oxidation: The large surface area of nanoparticles
            in the shape of a solenoid and can be installed on a soft   makes them susceptible to oxidation, potentially
            robot, such as a snake, to distinguish tensile and bending   compromising their long-term performance.
            deformations.
                                                               3.3. Perovskites
              Extrusion-based 3D printing has been considered the
            predominant approach for fabricating soft sensors embedded   Perovskite materials have attracted considerable interest in
                                                               the semiconductor field due to their unique characteristics,
            with metallic powder. However, a limited but notable   such as strong absorption coefficients, excellent tolerance
            alternative  has  been  reported:  vat  photopolymerization   to defects, and high charge carrier mobility. 76-78  Perovskites
            printing.  Photopolymerization-based printing  is only   generally possess ABX  structure, where A and B represent
            applicable to photosensitive resins, and metallic powders   cations, and X represents an anion (A: MA  or FA  or
                                                                                 3
                                                                                                          +
                                                                                                    +
            may absorb and reflect light, potentially impeding sufficient   Cs , B: Pb  or Sn , X: Cl or Br or I ). The enhanced
                                                                                      -
                                                                                           -
                                                                                               -
                                                                 +
                                                                        2+
                                                                              2+
            light penetration into the material. These limitations can   photoluminescence quantum yield (PLQY) and superior
            result in incomplete curing of the material and degradation   color purity inherent to perovskites significantly enhance
            of mechanical properties.  In addition, metallic powders   the power conversion efficiency (PCE) in solar cells. 79-83
            have high thermal conductivity, which can concentrate   Furthermore, their broad wavelength spectrum facilitates
            heat energy generated during the photopolymerization   the generation of diverse light colors in LEDs, which
            process onto the soft material, leading to thermal damage   plays a critical role in achieving high-resolution display
            or deformation of the material.                    technologies. 84,85  Moreover, these properties are critically
              To circumvent these limitations, hybrid 3D printing that   harnessed in engineering highly sensitive sensors capable of
            integrates the advantages of vat photopolymerization and   detecting subtle environmental alterations.  Conventional
                                                                                                 86
            extrusion-based 3D printing was developed. This approach   fabrication methods of perovskite devices include spin
            has demonstrated strain gauge fabrication.  The hybrid   coating,  spray coating,  and blade coating.  However,
                                               75
                                                                                                    89
                                                                     87
                                                                                   88
            3D printer combines DLP for high-resolution printing of   spin coating often leads to substantial material loss, spray
            a photosensitive matrix and DIW for printing conductive   coating poses challenges in controlling the uniformity of
            silver nanoparticle ink. Through optimization of printing   perovskite layer thickness, and blade coating encounters
            parameters, strong interfacial bonding between the DLP-  difficulties in fabricating ultrathin films.
