AMTransformer for process dynamics

decoder layers generally improved model performance, The AMTransformer achieved an SSIM of 0.9206,
with six layers achieving the best SSIM of 0.9206, an MAE which is higher than the SSIMs of the transformer with
of 0.0009 mm , and an accuracy of 92.73%. While adding a basic autoencoder (0.8699) and the ConvLSTM model
2
more layers slightly enhanced MAE and accuracy, it had a (0.9069). This result indicates that the AMTransformer can
negligible effect on SSIM. Thus, a six-layer configuration predict the MPM images more accurately than the other
was deemed the most suitable for achieving high image models. For melt pool size prediction, the AMTransformer
2
congruence. achieved an MAE of 0.0009 mm , whereas the transformer
with a basic autoencoder and ConvLSTM had MAEs of
Table 2 presents the results of varying the number 2 2
of attention heads while keeping the six decoder layers 0.0017 mm and 0.0014 mm , respectively. In addition, the
proposed method for predicting melt pool size achieved
constant. The configuration with four attention heads an accuracy of 92.73%. Table 3 displays the comparison of
was the most effective, delivering the highest SSIM and model performance. According to the results, the AM –
an optimal MAE while maintaining good accuracy. Transformer demonstrated the best overall performance.
Increasing the number of attention heads slightly decreased Figure 11 presents a comparison between the predicted
performance, likely due to the complexity of the LPBF tool and target images, illustrating the correspondence between
path. While each head captures distinct local patterns, there the model’s outputs and the ground truth.
can be interdependencies between embeddings processed
by different heads. For instance, the initial embeddings 6. Discussion
from the first head may have strong relationships with the
last embeddings of the sixth head when they are spatially In the framework of the AMTransformer, the proposed AM
close but temporally distant. This observation indicates dynamics formulation links the Koopman and transformer
approaches to AM data. These approaches complement each
a need for future research on AM-specific multi-head other by leveraging their respective strengths for AM. The AM
attention mechanisms, which will be discussed further in state embedder improves the learning of significant features
Section 7.
of physical properties and their dynamical dependencies
Based on these findings, we selected the configuration for each AM state within the embeddings, which are latent
with six decoder layers and four attention heads, as it offered vector representations of these physical property features
the best overall performance across all metrics. With this and dependencies at each time step. In addition, in our
configuration set, we compared the AMTransformer’s study, the adaptation of the Koopman operator with AM
performance against other models, including a transformer state embeddings in latent space representations focuses
with a basic autoencoder and a ConvLSTM model. on transforming non-linear dynamical AM systems into a
linear framework. This transformation enables improved
Table 1. Performance comparisons across a varying number analysis and prediction of key dynamical dependencies in
of decoder layer AM using a linear method. The Koopman operator can
linearize aspects of the dynamical dependencies that are
2
Layer SSIM MAE (mm ) Accuracy (%) amenable to linear analysis, providing a robust foundation
2 0.4163 0.0057 21.87 for understanding underlying AM dynamics. In the
4 0.7815 0.0016 77.52 case study, by comparing the AMTransformer with the
6 0.9206 0.0009 92.73 transformer using a basic autoencoder, we explored how the
8 0.9169 0.0008 93.04 AM state embedder with the Koopman operator improves
Notes: MAE: Mean absolute error; SSIM: Structural similarity index the understanding of AM dynamics.
measure. Meanwhile, the adaptation of the transformer, which
employs a multi-head attention mechanism, is adept at
Table 2. Variations in the number of attention heads with six
decoder layers Table 3. Comparison of performance across models
Head SSIM MAE (mm ) Accuracy (%) Model SSIM MAE (mm ) Accuracy (%)
2
2
2 0.7584 0.0041 44.6 AMTransformer 0.9206 0.0009 92.73
4 0.9206 0.0009 92.73 Basic AE+Transformer 0.8699 0.0017 70.55
8 0.9047 0.0011 90.13 ConvLSTM 0.9069 0.0014 89.50
16 0.8518 0.0013 83.32 Notes: AE: Autoencoder; ConvLSTM: Convolutional long short-term
Notes: MAE: Mean absolute error: SSIM: Structural similarity index memory; MAE: Mean absolute error; SSIM: Structural similarity index
measure. measure.
