International Journal of Bioprinting                                   3D cartilage induction and monitoring




               Transition layers were marked as interior impedances:   will mostly depend on the scaffold’s speed of sound and
                                                               density. By substituting the equation with bulk modulus
                          Z = ρ  • C m                 (VI)    (K) (Equation (9)), P-wave propagation can be defined as
                              m
                           i
                                                               Equation (10).
               where  ρ  and  c  are parameters from the reflective
                            m
                     m
                                                                                    (1
            material.                                                        K =   E − v)                 (IX)
               Finally, a boundary probe was attached to the                     (1 + v)(1 −2 v)
            transducer to obtain the final electrical modeled signal. No
            initial potential was computed for the piezo; instead, the
            floating potential was selected as the outer potential.            C =  K                      (X)
                                                                                p
               A 2D model was selected as it could drastically                      ρ
            reduce  the  computational  time,  memory  requirements,
            and representation complexity. All previous parameters   With that in mind, a set of signals were synthetically
                                                                                                      −1
            are essential to compute inverse problem studies where   created, with varying C  from 1300 to 1600 m·s  and ρ −3
                                                                                  SD
                                                                                                            SD
            parametric sweeps are performed. Contrasting the   (density of the scaffold domain) from 1000 to 1400 kg·m .
            previous model that describes the microfluidic flow, the   Thereafter, empirical signals obtained from the BR ex vivo
            porosity of this model has not been computed due to the   experiments were compared with the set of signals.
            higher wavelength of the ultrasound P-wave through the
            scaffold domain than the PS: 47                                                               (XI)

                               C
                          λ =   SD  f                 (VII)       Each empirical signal was cross-correlated, with each
                           SD
                                   0
                                                               synthetical signal generated using the computational model.
                                                               Every synthetic signal was tagged with its corresponding
               where the speed of sound of the scaffold domain (c ) >    ρ  and  C . It was estimated that the maximum cross-
                                                       SD
                                                                SD
            1480 m·s , cutoff frequency (ƒ ) = 1 MHz, and thus, λ  >    correlation (>80%)  correlated with optimal density and
                   −1
                                                                       SD
                                                       SD
                                    0
            1.48  mm,  resulting in  PS  <  400  µm.  Mesh  element  size   speed of sound.
            was selected through parameter sweep to verify model
            convergence (Figure S3, Supporting Information). It was   To validate the present model, BR was assembled in
            established that an element size below 400 µm is sufficient   two different manners: without any scaffold (and filled
            to acquire a stable signal. In  Figure S3G–J, Supporting   with water) and with a solid disk of PLA (and filled with
            Information,  no  significant variance  over  amplitudes  in   water). In previous literature, both the density and speed
                                                                                                    48
            mesh sizes below 400 µm can be appreciated. The rest   of sound of the materials have been disclosed.  The speed
            of the parameters (i.e.,  c PMMA ,  c H2O ,  ρ PMMA , and  ρ H2O ) was   of sound of PMMA was empirically calculated to be 2630
                                                                                                            −1
                                                                                                         −
                                                                  −1
                                                                                                    6
            reconstructed through the inverse problem.         m·s , with an acoustic impedance of 3 × 10  kg·m ²·s .
                                                               Figure S2, Supporting Information, represents the level
               Further, P-wave propagation models should consider   of correlation between the water model (Figure S2A and
            the mechanical behavior of three different materials   C, Supporting Information) and the PLA model (Figure
            (PMMA, water, and bTPUe). Thus, the final electrical   S2B and D, Supporting Information). A signal correlation
            signal, representing the ultrasonic pulse, envelops all such   (comparing  synthetic  and  experimental  signals)  higher
            parameters, thereby complicating the data extraction   than 80% was obtained in both cases.
            process. Additionally, the computer model focused on the
            reconstructive parameters that had more variability over   3. Results
            time. Therefore, P-wave propagation can be presented
            based on the speed of the longitudinal wave:       3.1. Perfusion bioreactor with pulsed ultrasound
                                                               characterization
                                                               A novel BR was designed to promote perfusion flow and
                                   (1
                                  E − v)
                         C =   ρ (1 + v)(1 −2 v)     (VIII)    exert direct shear stress on the cell surface among scaffold
                          p
                                                               fibers to induce chondrogenesis (Figure 1A). PMMA
                                                               was selected for this study, owing to its effortless sterility,
               where E denotes the Young’s modulus. This equation   transparency, and economical manufacturing cost. The BR
            estimates that the final signal obtained by the transducer   is mainly composed of three different pieces: the culture
