Materials Science in Additive Manufacturing                Y O  influence in heat-treated LPBF IN718 composite
                                                                        2  3

            below the critical diameter. In addition, due to the small   Figure 11. A thorough quantitative analysis of the Orowan
            volume fraction of the added nanoparticles, the fraction   strengthening is challenging in heat-treated samples
            of the nanoparticles that can contribute to strengthening   since there are numerous types of nano-sized precipitates
            is also small.                                     (carbonitride precipitates, Y O  nanoparticles, Y-Ti-O
                                                                                         3
                                                                                       2
                                                               nanoparticles,  γ′  and  γ′′  precipitates,  and  δ and blocky
              Furthermore, the previously calculated results of the
            strengthening contribution are based on the CTE mismatch   Laves phase) that each contributes to the strength of the
            between the Y O  nanoparticles and the IN718 matrix.   material differently. Furthermore, the morphology of
                          3
                        2
            However, it has been pointed out that the nanoparticles   the majority of the precipitates is not spherical and their
            have a high tendency to combine with the carbonitride   distribution in the matrix may not be homogeneous.
            shell to form a complex precipitate. As such, it would be   Thus, these factors make quantifying the contribution
            more appropriate to compare the CTE mismatch between   of the precipitates to the strength of the material highly
                                                               challenging. However, an appropriate qualitative analysis
            the Y O  nanoparticles and the carbonitride shell. Since   to  explain the differences in the material’s  strength  can
                  3
                2
            the CTE of the shell is in the range of 6.65 × 10 K  to
                                                       −1
                                                    −6
            8.48 × 10 K −1[53] , which is much closer to that of the Y O    still be carried out.
                   −6
                                                          3
                                                        2
            nanoparticles than IN718 is, the actual increase in strength   First, the number of nano-sized precipitates in the
            is again expected to be small. Due to these reasons, the   Y O -reinforced  sample  is  expected  to  be  higher than  in
                                                                2
                                                                  3
            contribution of  CTE  mismatch  strengthening  in  the   the monolithic sample due to the formation of the Y-Ti-O
            IN718/Y O  composite will be omitted.              precipitates after solutionizing treatment (Figure 10A).
                   2  3
              Finally,  the  load  transfer  mechanism,  ∆   can  be   As such, these precipitates increase the strength of the
            calculated using Equation V [42,54] .  load        IN718/Y O  composite after heat treatment. Furthermore,
                                                                        3
                                                                      2
                                                               these precipitates also contribute to grain refinement after
                            load   05.  f p  m     (V)     heat treatment since they act as nucleation centers for the
                                                               recrystallization of grains at high temperatures and at the same
              Where   is the yield strength of the matrix. It can be   time, suppress grain growth. Hence, this further enhances the
                      m
            seen from Equation V that the contribution of the load   material’s strength through grain boundary strengthening.
            transfer mechanism is expected to be small as the volume   Second, it is theorized that the difference in the Laves
            fraction,  f , of the reinforcement particles is very small.   phase morphology at the grain boundaries between the
                    p
            Coupling with the 0.5 coefficient, the load transferring
            mechanism  is  believed  to be  not  at  play,  which  is  also   Y O -reinforced samples and the monolithic samples as
                                                                  3
                                                                2
                                                               shown in  Figure 8 also contributes to the difference in
            verified by Wang et al. [42]
                                                               the mechanical properties. However, after solutionizing
              Thus, it can be seen that the majority of the strengthening   treatment at 1075°C,the microstructural changes resulting
            mechanisms do not result in a significant improvement in   from additional aging treatment are not obvious. Thus, it
            the strength of sample AP-Y. In fact, the strength of sample   is challenging to accurately characterize the differences.
            AP-Y is slightly lower than that of sample AP-0. This is   As such, to accurately characterize the differences in
            because the theoretical calculation does not consider the   the microstructures that arise from aging treatment
            agglomeration of the Y O  nanoparticles. This further   and to understand the reasons behind any changes in
                                2
                                  3
            supports the observations made in Section 3.1 in which   mechanical properties after aging treatment, both samples
            there is a high concentration of Y O  in the interdendritic   are  solutionized  at  1275°C before aging.  This is  because
                                         3
                                       2
            regions. As a result, this overestimated the strengthening   when the samples are solutionized at this temperature,
            contribution of the Orowan mechanism. Furthermore,   the diffusion of different alloying elements is significantly
            several other factors could potentially overestimate the   enhanced . As such, the movements of the alloying
                                                                       [55]
            Orowan  strengthening  mechanism  such  as  not  all  the   elements during heat treatment can be visualized.
            particles being spherical and the mean particle diameter   SEM analysis of sample 1275A-Y shows that the addition
            values being inaccurate to represent the entire size   of Y O  has resulted in grain refinement. This is evident in
                                                                  2
            distribution. Thus, due to the similar grain sizes, the   Figure 12 showing a significantly higher number of smaller
                                                                    3
            small volume fraction of reinforcement particles, and   equiaxed grains in sample 1275A-Y compared to sample
            the presence of carbonitride precipitates in sample AP-0,   1275A-O. It is also observed that the segregated regions
            the strengths of the as-printed samples only differ slightly.  (red color) are thinner in sample 1275A-Y than those in
              However,  in this  study,  the  value  added  of  the   sample 1275A-0. This further reinforced the phenomenon
            reinforcement  particles  in  strengthening  IN718  in which the addition of Y O reduces the segregation at
                                                                                     2
                                                                                       3
            can only be realized after heat treatment as seen in   the grain boundaries as shown in Figure 8.
