Materials Science in Additive Manufacturing Heat treatment on bimetallic parts

A

B C

D E

F G

Figure 8. Microstructural analysis of interfaces. (A) Elemental mapping covering an oxide inclusion and secondary phase. Scale bars: 10 μm, magnification:
×3678; Scale bars: 2 μm, magnification: ×3678. Energy-dispersive X-ray spectroscopy (EDS) line scans for light (B) and dark (C) areas; elemental analyses
for specific spots: (D) analysis at spot D, (E) analysis at spot E; (H) EDS line scans for white band.

Table 4. Element distribution in the interface of bimetal phases, as depicted in Figure 9A. The primary phases in
17-4PH are the α-phase (martensitic and ferritic phases),
Weight % Cr Fe Ni Nb Mo Mn Si C O whereas in IN625, the dominant phase is the γ-phase
Precipitates 9.7 5.1 20.9 25.8 15.9 - 2.1 16.5 2.3 (austenitic phase). No additional phases were discovered
Oxides 39.5 - - - - 19.5 0.5 8.7 30.4 following the heat treatments, which were under 1150°C
White bands 14.8 51.9 14.6 - 1.4 - 0.3 10.6 - for various durations, with or without subsequent
17-4PH 12.6 57.6 3.1 - - 0.4 2.8 9.1 7.0 aging, of 17-4PH, with only austenite and martensite
20
IN625 18.5 5.8 52.0 2.6 7.0 - 0.6 11.6 1.9 peaks detected. Both direct aging and aging following
Hot Isostatic Pressing (HIP) of 17-4PH fabricated
through PBF showed no formation of other phases. 31,47
slower cooling rate. The elongated morphology of these Furthermore, the absence of additional peaks suggests the
46
carbides is due to the slow cooling rates experienced at absence of reactive phase formation within the bimetallic
the conclusion of the heat treatment process, a detail that structure of SS316L and IN718 alloy. Similarly, further
48
aligns with the observed structural characteristics. XRD patterns corroborate the observation in our
The XRD patterns of phases present at the 17-4PH/ research that no new intermetallic phases form within
IN625 composite, both in as-sintered and heat-treated the diffusion zone following heat treatment, aligning
states, were analyzed to assess changes in intermetallic with the findings from EDS analyses. Independent of
