Page 163 - TD-3-4

Tumor Discovery CK2 deregulation in non-small-cell lung cancer

A

B

C

Figure 5. Immunohistochemical detection of CK2 subunits and CK2 substrate phosphorylation (AKT) in LUAD specimens and para-neoplastic tissues.
Representative staining results for each CK2 subunit are shown: (A) in tumor and (B) in para-neoplastic tissues as a brown color; (C) Total AKT and
phosphorylated AKTs129 (pAKT) protein levels were measured in tumor (LUAD) and para-neoplastic (Para-) tissues as an indicator of CK2 enzymatic
activity in situ. Images were captured at 200× magnification. Scale bars: 100 μm.
Abbreviations: LUAD: Lung adenocarcinoma; CK2: Casein kinase-2.

Table 1. Immunohistochemical detection and quantification using a combined immunoreactivity score for independent CK2
subunits in primary tumor specimens of NSCLC and para-neoplastic tissues
Groups Sample size Score Positive rate z-score P-value
− + ++ +++
CK2A1
NSCLC 134 30 50 27 27 77.6 −9.864 0.000
Para-neoplastic 134 107 24 2 1 20.1 0.000
CK2A2
NSCLC 134 16 55 41 21 88.1 −7.248 0.000
Para-neoplastic 134 65 49 16 4 51.5 0.000
CK2B
NSCLC 134 13 48 35 38 90.3 −8.538 0.000
Para-neoplastic 134 76 35 18 5 43.3 0.000
Ki-67
NSCLC 134 58 32 20 24 56.7 −9.722 0.000
Para-neoplastic 134 131 3 0 0 2.2 0.000
Notes: Score 1 – 3: − (negative); Score 4 – 5: + (weak positive); Score 6 – 7: ++ (positive); Score ≥8: +++ (strong positive); Two-sided P<0.05 was
considered statistically significant for all calculations.
Abbreviation: NSCLC: Non-small-cell lung cancer.

2/2, and 3/3 significant unique analyses, respectively, 16 additional tumor types indicated cancer-type-specific
involving lung cancer specimens. In addition, Kaplan– up- or downregulation of CSNK2 transcripts, as well as
Meier analysis revealed a significant correlation between direct and inverse correlations between CSNK2 transcripts
CSNK2B overexpression and reduced OS, while CSNK2A2 and OS. Overall, the prevailing notion is that CK2’s
27
overexpression was unexpectedly associated with aberrant expression levels or activity are instrumental to
improved OS in LUAD. A follow-up analysis analyzing malignant transformation and promotion; however, the
26

Volume 3 Issue 4 (2024) 9 doi: 10.36922/td.4571
