International Journal of Bioprinting                       Wireless module system applied on 3D-printed implant




            1. Introduction                                    and peripheral measurement systems for data collection.
                                                               As a result, current strain sensing devices do not facilitate
            Mandibular continuity defects refer to obvious bone or tissue   real-time measurements performed by patients themselves
            loss in the mandibular region, primarily caused by malignant   or within a home setting. Therefore, the prime objective of
                                                         1-3
            tumors, external traumas, or congenital genetic disorders.    this study is to integrate the strain gauge signal processor
            These defects can have a detrimental impact on a patient’s   into a microchip that can be installed into mandibular
            facial aesthetics and may lead to speech and chewing   implants to monitor the implant’s biomechanical status at
            difficulties, affecting their quality of life.  Currently, fibula   the initial period after surgery.
                                            4
            free flap (FFF) surgery used with traditional bone plates to
            secure the bone graft is the gold standard for such treatments.   In this study, we developed a miniaturized WMS for
            Several advantages of this approach include the exit of the   strain gauge measurement to achieve early biomechanical
            fibular flap from the long vascular pedicle, segmented blood   behavior detection in an experimental 3D-printed metal
            supply, availability as a composite tissue, and enough bone   model of a patient-specific segmental implant (MMPSI)
            volume for host dental implants.  However, reconstruction   after surgery. This system was installed into a 3D-printed
                                     5-7
            procedures remain challenging for surgeons because bone   mandibular implant for in vitro fatigue mechanical testing
            plate fatigue fractures may occur due to pre-bent implants to   under different occlusal conditions applied on the simulated
            conform to the mandibular curvature. 8-10  Furthermore, these   plastic mandibular model after validating the feasibility
            implants may not precisely match the patient’s mandibular   through  cantilever  beam  modeling  and  mechanical
            curvature, resulting in the inability to fully restore patient   tests. The goal was to prevent premature failure through
            appearance and bite functionality.                 understanding the relationship between the received strain
                                                               signals  from  the  in vitro  simulated mandibular  patient-
               Recently, metal three-dimensional (3D) printing,   specific 3D-printed implant and various occlusal forces.
            medical image processing, and computer-aided design
            (CAD) technologies were integrated to develop a patient-  2. Materials and methods
            specific reconstruction implant for mandibular continuity
            defect. This approach was accepted to restore the patient   2.1. WMS design
            appearance and mandible structural strength.  However,   The CYBLE-214015-01 (Infineon Technologies, Neubiberg,
                                                 11
            metal 3D-printed implants introduce certain challenges,   Germany) programmable microchip with a built-in low-
            particularly in terms of implant weight and the potential   power Bluetooth module was employed in this study. The
            stress-shielding effect.  To address these issues, topology   internal amplifier and 12-bit analog-to-digital microchip
                              12
            optimization was proposed to preserve the implant   converter were utilized for strain gauge signals acquisition
            mechanical strength while reducing its excessive weight.    at a sampling rate of 1500 Hz. The signals, following
                                                         13
            Nonetheless, the instability of large 3D-printed implant is   median filtering, were transmitted to a mobile application
            usually associated with their unfavorable biomechanical   (APP) via low-power Bluetooth connection at a rate of 20
            aspects, including experiencing high stress/strain and   data points per second. To achieve power efficiency, the
            significant displacement. Abnormal biomechanical   microchip system automatically entered a sleep state in case
            responses to the 3D-printed implant can result in implant   of transmission interruption. The chip awakened to resume
            loosening/extensive damage, and the implant might also   data capture and transmission upon re-establishing the
            become dislodged, penetrating through the adjacent   Bluetooth connection. The program design is illustrated in
            soft tissue. 14,15  Therefore, ensuring the early detection of   Figure 1a. The microchip underwent fabrication processes
            biomechanical anomalies in large implants is a critical   such as exposure, development, and etching, as depicted in
            consideration for mandibular reconstruction treatment.  Figure 1b. This chip measured 17.5 mm in length and 12 mm
                                                               in width. The primary mobile APP functions can record data
               Strain gauge used to measure deformation resulting   with data saved in text format and allow the APP interface
            from bending forces is a well-established technique in   to adjust the adaptation of both the Bluetooth connection
            both  the  mechanical  and  medical  fields.   Strain  gauges   time and the sleep interval time with the microchip to
                                             16
            work by utilizing piezoelectric materials to deform and   reduce chip power consumption. In subsequent steps, the
            then amplify the voltage, pass it through a Wheatstone   strain gauge and power wires were sequentially soldered to
            bridge, and convert it into the strain measurement for the   the wireless module chip, forming a WMS to communicate
            tested object. In recent years, placing strain gauges within   with the mobile APP (Figure 1c).
            a bone plate has been proposed to detect and track post-
            operative bone healing conditions. 17,18  However, the strain   2.2. WMS validation
            signals measurements typically require specific settings   Cantilever beam model structural mechanics were used to
            and the use of external wearable devices (such as wires)   validate the WMS feasibility. Finite element (FE) analysis


            Volume 10 Issue 3 (2024)                       605                                doi: 10.36922/ijb.2553
