International Journal of Bioprinting Biomechanical analysis of mandibular implants

Figure 8. High-stress distribution in samples with various lattice shapes and sizes: (a) for tetrahedron lattice designs, only stresses exceeding 1000 MPa
are displayed, (b) for hex-vase lattice designs, only stresses exceeding 1000 MPa are displayed, (c) for hex-star lattice designs, only stresses exceeding 1000
MPa are displayed, and (d) for quad-diametral-cross lattice designs, only stresses exceeding 1000 MPa are displayed.

within the lattice gradually increased, and the regions with relatively low high-stress distributions, were compared.
high-stress distributions gradually expanded for all four Therefore, these two designs were selected for the next
lattice shapes. phase of experimentation.

With consideration of the results regarding the lattice 3.2. In vitro experimental test
rod diameters (Figure 9), the lattice designs of quad- In the lattice designs of quad-diametral-cross and hex-
diametral-cross and hex-vase, both of which exhibited vase, a significant increase was observed in the elastic
