Shuai Wang, Jia Min Lee and Wai Yee Yeong

erties of hydrogels. However, these tests might induce folds [106] .
hydrogel deformation that contributes to measurement
errors. In the compression of a hydrogel, mechanical 6. Conclusion
properties are calculated based on load and hydrogel Smart hydrogels are an interesting class of materials
displacement on the Z-axis [101] . As water was being that could be programmed to react to specific stimuli
compressed out of the hydrogel material during mea- such as pH, temperature, light, electric, and magnetic
surement, the mechanical properties of the hydrogel field. Successful printing of smart hydrogel materials
changed over the course of the test. To overcome the will call for a comprehensive understanding of the
limitations of destructive tests, non-destructive cha- materials, bioprinting systems, and bioprinting
racterization method such as indentation test was in- processes. Looking into the future, new characteriza-
troduced. Using an atomic force microscope, the hy- tion and modelling methods are needed to aid the sys-
drogel was indented at a single point. The applied tematic investigation of applying smart hydrogels in
force and depth can be monitored to calculate the hy- bioprinting. With interdisciplinary collaborative inves-
drogel’s mechanical properties [102] . The challenge of
this method is to optimize the contact of the probe tigation, it is predicted that smart hydrogels could re-
without unintentional adhesion to the hydrogel volutionize bioprinting technologies and bring ahead
surface [103] . 3D as well as 4D bioprinting in the future.

5.3 Formulation of Hydrogel Materials Blend for Conflict of Interest and Funding
Printability No conflict of interest was reported by the authors.
It is a challenge to formulate a specific bioprintable References
ink with good printability. There is a trend in creating
a blend of hydrogel materials for added versatility in 1. Guillemot F, Mironov V and Nakamura M, 2010, Bio-
bioprinting. For example, in cartilage engineering, printing is coming of age: report from the International
photocrosslinkable glycosaminoglycan-based hydro- Conference on Bioprinting and Biofabrication in Bor-
gels are chondrogenic, but have generally poor print- deaux (3B'09). Biofabrication, vol.2(1): 010201.
ing properties on their own. By blending the thermo- http://dx.doi.org/10.1088/1758-5082/2/1/010201.
responsive polymer poly(N-isopropylacrylamide) 2. Seol Y-J, Kang H-W, Lee S J, et al. 2014, Bioprinting
grafted hyaluronan (HA-pNIPAAM) with methacry- technology and its applications. European Journal of
lated hyaluronan (HAMA), high-resolution scaffolds Cardio-Thoracic Surgery, vol.46(3): 342–348.
with good viability were printed [104] . Therefore, inter- http://dx.doi.org/10.1093/ejcts/ezu148.
disciplinary collaboration is needed among material 3. Seliktar D, Dikovsky D and Napadensky E, 2013, Bio-
research, biological research, and mechanical systems printing and tissue engineering: recent advances and fu-
engineering to achieve the ideal hydrogel formulation ture perspectives. Israel Journal of Chemistry, vol.53(9–
for bioprinting. 10): 795–804.
http://dx.doi.org/10.1002/ijch.201300084.
5.4 Bio-origami or 4D Bioprinting
4. Bajaj P, Schweller R M, Khademhosseini A, et al. 2014,
Certain types of polymers such as Poly(N-isopropy- 3D biofabrication strategies for tissue engineering and
lacrylamide) (PNIPAAm) is among the most popular regenerative medicine. Annual Review of Biomedical
temperature-responsive polymers because its phase Engineering, vol.16: 247–276.
transition temperature is close to physiological tem- http://dx.doi.org/10.1146/annurev-bioeng-071813-10515
perature [50] . For example, a crosslinked bilayer was 5.
fabricated using PNIPAAm and water-insoluble po- 5. Murphy S V and Atala A, 2014, 3D bioprinting of tissues
lymer poly(ε-caprolactone) (PCL). From this bilayer and organs. Nature Biotechnology, vol.32: 773–785.
gel, four- and six-armed capsules were fabricated. It http://dx.doi.org/10.1038/nbt.2958.
can self-fold or self-unfold in response to temperature 6. Arafat M T, Gibson I and Li X, 2014, State of the art and
change with the application of yeast cell future direction of additive manufactured scaf-
encapsulation [105] . This group of materials have a po- folds-based bone tissue engineering. Rapid Prototyping
tential in bioprinting with the possibility of creating Journal, vol.20(1): 13–26.
4D bioprinted structures or bio-origami hydrogel scaf- http://dx.doi.org/10.1108/RPJ-03-2012-0023.
